PMPB12EPX
lmages are for reference only.PMPB12EPX
MOSFET P-CH 30V 7.9A DFN2020MD-6
Datasheet6-UDFN Exposed Pad
31,835 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
P-Channel 30 V 7.9A (Ta) 1.7W (Ta), 13W (Tc) Surface Mount DFN2020MD-6
PMPB12EPX
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Nexperia USA Inc. |
| Series | TrenchMOS™ |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| FET Type | P-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 30 V |
| Current - Continuous Drain (Id) @ 25°C | 7.9A (Ta) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Rds On (Max) @ Id, Vgs | 17.3mOhm @ 7.9A, 10V |
| Vgs(th) (Max) @ Id | 2V @ 250µA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 227 pF @ 15 V |
| FET Feature | - |
| Power Dissipation (Max) | 1.7W (Ta), 13W (Tc) |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | DFN2020MD-6 |
| Package / Case | 6-UDFN Exposed Pad |
| Base Product Number | PMPB12 |
| Gate Charge (Qg) (Max) @ Vgs | 39.9 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
 |
 |
| Part Number | PMPB12R5EPX | PMPB12R5UPEX | PMPB12R7EPX | PMPB12UN,115 |
| Manufacturer | Nexperia USA Inc. | Nexperia USA Inc. | Nexperia USA Inc. | NXP USA Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | PMPB12R5EP - 30 V, P-CHANNEL TRE | PMPB12R5UPE/SOT1220-2/DFN2020M | PMPB12R7EP - 30 V, P-CHANNEL TRE | MOSFET N-CH 20V 7.9A 6DFN |
| Series | TrenchMOS™ | - | TrenchMOS™ | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
