PV-125A-2XL-3B-15
lmages are for reference only.PV-125A-2XL-3B-15
FUSE 125A 1500V 2XL PV BOLT-IN V
DatasheetRectangular, Blade
49,329 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
125A 1.5 kVDC Fuse Square Bolt Mount
PV-125A-2XL-3B-15
| Category | Circuit Protection - Electrical-Specialty Fuses - |
| Manufacturer | Eaton - Bussmann Electrical Division |
| Series | XL |
| Packaging | Bulk |
| RoHS Status | |
| Mounting Type | Bolt Mount |
| Fuse Type | Square |
| Current Rating (Amps) | 125A |
| Voltage Rating - AC | - |
| Response Time | Fast Blow |
| Applications | Solar (Photovoltaic) |
| Features | Indicating |
| Class | gPV |
| Approval Agency | CE, EAC, UL |
| Operating Temperature | - |
| Breaking Capacity @ Rated Voltage | 30kA |
| Package / Case | Rectangular, Blade |
| Size / Dimension | 5.118" L x 2.323" W x 2.992" H (130.00mm x 59.00mm x 76.00mm) |
| Base Product Number | - |
| Voltage Rating - DC | 1.5 kVDC |
| Grade | - |
| Qualification | - |
| Melting I²t | 2200.0 |
| DC Cold Resistance | - |
| Product Attribute |  |
|
|
|
| Part Number | PV-125A-2XL-15 | PV-125A-2XL-B-15 | PV-125A-01XL | PV-125A-01XL-15 |
| Manufacturer | Eaton - Bussmann Electrical Division | Eaton - Bussmann Electrical Division | Eaton - Bussmann Electrical Division | Eaton - Bussmann Electrical Division |
| RoHS Status | RoHS Compliant | RoHS Compliant | RoHS Compliant | RoHS Compliant |
| Description | FUSE 125A 1500V 2XL PV | FUSE 125A 1500V 2XL PV BOLT-IN V | FUSE 125A 1000V 1 XL PV | FUSE 125A 1500V 1 XL PV |
| Series | * | * | * | * |
| Packaging | Bulk | Bulk | Bulk | Bulk |
