R10-E1L6-S320
lmages are for reference only.R10-E1L6-S320
RELAY GEN PURPOSE 6PDT 7.5A 12V
Datasheet-
30,854 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
General Purpose Relay 6PDT (6 Form C) 12VDC Coil Socketable
R10-E1L6-S320
| Category | Relays - Power Relays-Over 2 Amps - |
| Manufacturer | TE Connectivity Potter & Brumfield Relays |
| Series | R10 |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Mounting Type | Socketable |
| Coil Voltage | 12VDC |
| Contact Form | 6PDT (6 Form C) |
| Contact Rating (Current) | 7.5 A |
| Switching Voltage | 120VAC - Nom |
| Load - Max Switching | - |
| Coil Current | 37.5 mA |
| Coil Type | Non Latching |
| Features | - |
| Termination Style | Plug In |
| Seal Rating | - |
| Coil Insulation | - |
| Must Operate Voltage | 9 VDC |
| Must Release Voltage | - |
| Operate Time | - |
| Release Time | - |
| Operating Temperature | -55°C ~ 75°C |
| Contact Material | Gold Platinum Silver (AuPtAg) |
| Approval Agency | CSA, UR |
| Relay Type | General Purpose |
| Grade | - |
| Qualification | - |
| Coil Resistance | 320 Ohms |
| Base Product Number | R10-E1L6 |
| Product Attribute |  |
 |
 |
 |
| Part Number | R10-E1M2-S3.2K | R10-E1M2-V700 | R10-E1M4-V700 | R10-E1M6-V430 |
| Manufacturer | TE Connectivity Potter & Brumfield Relays | TE Connectivity Potter & Brumfield Relays | TE Connectivity Potter & Brumfield Relays | TE Connectivity Potter & Brumfield Relays |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | RELAY GEN PURPOSE DPDT 5A 24V | RELAY GEN PURPOSE DPDT 5A 24V | RELAY GEN PURPOSE 4PDT 5A 24V | RELAY GEN PURPOSE 6PDT 5A 24V |
| Series | TE Connectivity Potter & Brumfield Relays | TE Connectivity Potter & Brumfield Relays | TE Connectivity Potter & Brumfield Relays | TE Connectivity Potter & Brumfield Relays |
| Packaging | Bulk | Bulk | Bulk | Bulk |
