R1223N202H-TR-FE
Manufacturer
RicohDescription
R1223N - 13.2V Input PWM/VFM Ste
Datasheet
DatasheetPackage
SC-74A, SOT-753
In Stock
80,300 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
R1223N202H-TR-FE
R1223N202H-TR-FE
lmages are for reference only.Payment Methods
Delivery Services
Buck Regulator Positive Output Step-Down DC-DC Controller IC SOT-23-5
Quick Inquiry
R1223N202H-TR-FE
Specifications
| Category | Integrated Circuits (ICs) - Power Management PMIC - DC DC Switching Controllers |
| Manufacturer | Ricoh |
| Series | - |
| Packaging | Bulk |
| RoHS Status | |
| Output Type | PWM |
| Function | Step-Down |
| Output Configuration | Positive |
| Topology | Buck |
| Number of Outputs | 1 |
| Output Phases | 1 |
| Voltage - Supply (Vcc/Vdd) | 2.3V ~ 13.2V |
| Frequency - Switching | 500kHz |
| Duty Cycle (Max) | - |
| Synchronous Rectifier | No |
| Clock Sync | No |
| Serial Interfaces | - |
| Control Features | Enable |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | SC-74A, SOT-753 |
| Supplier Device Package | SOT-23-5 |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
