Buck Regulator Positive Output Step-Down DC-DC Controller IC 18-HSOP
R1272S001A-E2-YE
| Category | Integrated Circuits (ICs) - Power Management PMIC - DC DC Switching Controllers |
| Manufacturer | Nisshinbo Micro Devices Inc. |
| Series | R1272S |
| Packaging | Tape & Reel (TR) |
| RoHS Status | RoHS Compliant |
| Output Type | Transistor Driver |
| Function | Step-Down |
| Output Configuration | Positive |
| Topology | Buck |
| Number of Outputs | 1 |
| Output Phases | 1 |
| Voltage - Supply (Vcc/Vdd) | 4V ~ 34V |
| Frequency - Switching | 250kHz ~ 1MHz |
| Duty Cycle (Max) | - |
| Synchronous Rectifier | Yes |
| Clock Sync | Yes |
| Serial Interfaces | - |
| Control Features | Enable |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 18-LFSOP (0.173", 4.40mm Width) Exposed Pad |
| Supplier Device Package | 18-HSOP |
| Base Product Number | R1272 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | R1272S001A-E2-FE | R1272S011A-E2-FE | R1272S012A-E2-FE | R1272S032A-E2-FE |
| Manufacturer | Nisshinbo Micro Devices Inc. | Nisshinbo Micro Devices Inc. | Nisshinbo Micro Devices Inc. | Nisshinbo Micro Devices Inc. |
| RoHS Status | RoHS Compliant | RoHS Compliant | ROHS3 Compliant | |
| Description | 34V INPUT PWM/VFM STEP-DOWN DCDC | 34V INPUT PWM/VFM STEP-DOWN DCDC | 34V INPUT PWM/VFM STEP-DOWN DCDC | 34V INPUT PWM/VFM STEP-DOWN DCDC |
| Series | R1272S | R1272S | R1272S | R1272S |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
