Buck, Boost Switching Regulator IC Positive and Negative Fixed -5.75V, 5.75V 2 Output 200mA 12-VFBGA, WLCSP
R1287Z004B-E2-F
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators DC DC Switching Regulators |
| Manufacturer | Nisshinbo Micro Devices Inc. |
| Series | R1287x |
| Packaging | Tape & Reel (TR) |
| RoHS Status | RoHS Compliant |
| Function | Step-Up/Inverted |
| Output Configuration | Positive and Negative |
| Topology | Buck, Boost |
| Output Type | Fixed |
| Number of Outputs | 2 |
| Voltage - Input (Min) | 2.5V |
| Voltage - Input (Max) | 5.5V |
| Voltage - Output (Min/Fixed) | -5.75V, 5.75V |
| Voltage - Output (Max) | - |
| Current - Output | 200mA |
| Frequency - Switching | 1MHz |
| Synchronous Rectifier | Yes |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 12-VFBGA, WLCSP |
| Supplier Device Package | WLCSP-12-P1 |
| Base Product Number | R1287 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | R1287L003H-TR | R1287Z001B-E2-F | R1287Z001C-E2-F | R1287Z001D-E2-F |
| Manufacturer | Nisshinbo Micro Devices Inc. | Nisshinbo Micro Devices Inc. | Nisshinbo Micro Devices Inc. | Nisshinbo Micro Devices Inc. |
| RoHS Status | RoHS Compliant | RoHS Compliant | RoHS Compliant | RoHS Compliant |
| Description | IC REG BUCK BST -5.4/5.4V 12DFN | IC REG BUCK BOOST ADJ DL 12WLCSP | IC REG BUCK BOOST ADJ DL 12WLCSP | IC REG BUCK BOOST ADJ DL 12WLCSP |
| Series | Nisshinbo Micro Devices Inc. | Nisshinbo Micro Devices Inc. | Nisshinbo Micro Devices Inc. | Nisshinbo Micro Devices Inc. |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR) |
