R5F566TEEDFF#30
lmages are for reference only.R5F566TEEDFF#30
IC MCU 32BIT 512KB FLASH 80LQFP
Datasheet80-LQFP
12,917 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
RXv3 RX66T Microcontroller IC 32-Bit Single-Core 160MHz 512KB (512K x 8) FLASH 80-LQFP (14x14)
R5F566TEEDFF#30
| Category | Integrated Circuits (ICs) - Embedded - Microcontrollers |
| Manufacturer | Renesas Electronics Corporation |
| Series | RX66T |
| Packaging | Tray |
| RoHS Status | ROHS3 Compliant |
| Core Processor | RXv3 |
| Core Size | 32-Bit Single-Core |
| Speed | 160MHz |
| Connectivity | CANbus, EBI/EMI, I2C, LINbus, MMC/SD, SCI, SPI, SSI, UART/USART |
| Peripherals | DMA, LVD, POR, PWM, WDT |
| Number of I/O | 52 |
| Program Memory Size | 512KB (512K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | 32K x 8 |
| RAM Size | 64K x 8 |
| Voltage - Supply (Vcc/Vdd) | 2.7V ~ 5.5V |
| Data Converters | A/D 19x12b; D/A 2x12b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 80-LQFP (14x14) |
| Package / Case | 80-LQFP |
| Base Product Number | R5F566 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
 |
 |
| Part Number | R5F566TEEDFF#10 | R5F566TEEDFH#10 | R5F566TEEDFH#30 | R5F566TEEDFM#10 |
| Manufacturer | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC MCU 32BIT 512KB FLASH 80LQFP | IC MCU 32BIT 512KB FLASH 112LQFP | IC MCU 32BIT 512KB FLASH 112LQFP | IC MCU 32BIT 512KB FLASH 64LFQFP |
| Series | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation | Renesas Electronics Corporation |
| Packaging | Tray | Tray | Tray | Tray |
