RCH875NP-5R1M
lmages are for reference only.RCH875NP-5R1M
FIXED IND 5.1UH 2.6A 21.2MOHM TH
DatasheetRadial, Vertical Cylinder (Open)
64,994 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
5.1 µH Unshielded Drum Core, Wirewound Inductor 2.6 A 21.2mOhm Max Radial, Vertical Cylinder (Open)
RCH875NP-5R1M
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Sumida America Components Inc. |
| Series | RCH-875 |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Type | Drum Core, Wirewound |
| Material - Core | Ferrite |
| Inductance | 5.1 µH |
| Tolerance | ±20% |
| Current Rating (Amps) | 2.6 A |
| Current - Saturation (Isat) | 4.2A |
| Shielding | Unshielded |
| DC Resistance (DCR) | 21.2mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -40°C ~ 100°C |
| Inductance Frequency - Test | 7.96 MHz |
| Features | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Vertical Cylinder (Open) |
| Supplier Device Package | - |
| Size / Dimension | 0.307" Dia (7.80mm) |
| Height - Seated (Max) | 0.295" (7.50mm) |
| Base Product Number | - |
| Product Attribute | |
|
|
|
| Part Number | RCH875NP-560K | RCH875NP-561K | RCH875NP-561K | RCH875NP-562K |
| Manufacturer | Sumida America Components Inc. | Sumida America Components Inc. | Sumida America Components Inc. | Sumida America Components Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | FIXED IND 56UH 730MA 180 MOHM TH | FIXED IND 560UH 230MA 1.72OHM TH | FIXED IND 560UH 230MA 1.72OHM TH | FIXED IND 5.6MH 69MA 18.7 OHM TH |
| Series | Sumida America Components Inc. | Sumida America Components Inc. | Sumida America Components Inc. | Sumida America Components Inc. |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR) |
