RN218-0.4-02-100M
lmages are for reference only.RN218-0.4-02-100M
CMC 100MH 400MA 2LN TH
DatasheetVertical, 4 PC Pin
73,340 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
100 mH @ 10 kHz 2 Line Common Mode Choke Through Hole 400mA DCR 2.8Ohm (Typ)
RN218-0.4-02-100M
| Category | Filters - Common Mode Chokes - |
| Manufacturer | Schaffner EMC Inc. |
| Series | RN |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Filter Type | Power Line |
| Number of Lines | 2 |
| Inductance @ Frequency | 100 mH @ 10 kHz |
| Current Rating (Max) | 400mA |
| DC Resistance (DCR) (Max) | 2.8Ohm (Typ) |
| Voltage Rating - DC | - |
| Voltage Rating - AC | 300V |
| Operating Temperature | -40°C ~ 100°C |
| Ratings | - |
| Approval Agency | ENEC, UR, VDE |
| Features | - |
| Mounting Type | Through Hole |
| Size / Dimension | 0.709" L x 0.492" W (18.00mm x 12.50mm) |
| Height (Max) | 0.799" (20.30mm) |
| Package / Case | Vertical, 4 PC Pin |
| Base Product Number | RN218 |
| Impedance @ Frequency | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | RN218-0.6-02-47M | RN218-0.7-02-39M | RN218-0.9-02-27M | RN204-0.6-02-4M4 |
| Manufacturer | Schaffner EMC Inc. | Schaffner EMC Inc. | Schaffner EMC Inc. | Schaffner EMC Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | CMC 47MH 600MA 2LN TH | CMC 39MH 700MA 2LN TH | CMC 27MH 900MA 2LN TH | CMC 4.4MH 600MA 2LN TH |
| Series | RN | RN | RN | RN |
| Packaging | Tube | Tube | Tube | Tube |
