RTX-104AF333-S-10.000-TR
lmages are for reference only.RTX-104AF333-S-10.000-TR
XTAL OSC TCXO 10MHZ 3.3V CLP SNW
Datasheet4-SMD, No Lead
56,107 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
10 MHz TCXO Clipped Sine Wave Oscillator 3.3V 4-SMD, No Lead
RTX-104AF333-S-10.000-TR
| Category | Crystals, Oscillators, Resonators - Oscillators - |
| Manufacturer | Raltron Electronics |
| Series | RTX-104 |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Base Resonator | Crystal |
| Type | TCXO |
| Frequency | 10 MHz |
| Function | - |
| Output | Clipped Sine Wave |
| Voltage - Supply | 3.3V |
| Frequency Stability | ±500ppb |
| Absolute Pull Range (APR) | - |
| Operating Temperature | -30°C ~ 85°C |
| Spread Spectrum Bandwidth | - |
| Current - Supply (Max) | 2mA |
| Ratings | - |
| Mounting Type | Surface Mount |
| Package / Case | 4-SMD, No Lead |
| Size / Dimension | 0.126" L x 0.098" W (3.20mm x 2.50mm) |
| Height - Seated (Max) | 0.051" (1.30mm) |
| Base Product Number | - |
| Product Attribute | |
|
|
|
| Part Number | RTX-104AF333-S-26.000-TR | RTX-104AF333-S-40.000-TR | RTX-104BD3C-S-26.000-TR | RTX-104BD3C-S-27.000-TR |
| Manufacturer | Raltron Electronics | Raltron Electronics | Raltron Electronics | Raltron Electronics |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | XTAL OSC TCXO 26MHZ 3.3V CLP SNW | XTAL OSC TCXO 40MHZ 3.3V CLP SNW | XTAL OSC TCXO 26MHZ CLP SNW | XTAL OSC TCXO 27MHZ CLP SNW |
| Series | Raltron Electronics | Raltron Electronics | Raltron Electronics | Raltron Electronics |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
