S2M0025120J
lmages are for reference only.S2M0025120J
MOSFET SILICON CARBIDE SIC 1200V
DatasheetTO-263-8, D2PAK (7 Leads + Tab), TO-263CA
39,188 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 1200 V 70A (Tj) 311W (Tc) Surface Mount TO-263-7
S2M0025120J
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | SMC Diode Solutions |
| Series | - |
| Packaging | Tube |
| RoHS Status | |
| FET Type | N-Channel |
| Technology | SiCFET (Silicon Carbide) |
| Drain to Source Voltage (Vdss) | 1200 V |
| Current - Continuous Drain (Id) @ 25°C | 70A (Tj) |
| Drive Voltage (Max Rds On, Min Rds On) | 20V |
| Rds On (Max) @ Id, Vgs | 34mOhm @ 50A, 20V |
| Vgs(th) (Max) @ Id | 4V @ 15mA |
| Vgs (Max) | +25V, -10V |
| Input Capacitance (Ciss) (Max) @ Vds | 4150 pF @ 1000 V |
| FET Feature | - |
| Power Dissipation (Max) | 311W (Tc) |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | TO-263-7 |
| Package / Case | TO-263-8, D2PAK (7 Leads + Tab), TO-263CA |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 177 nC @ 20 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | S2M0025120D | S2M0025120K | S2M0025120N | S2M0016120D-1 |
| Manufacturer | SMC Diode Solutions | SMC Diode Solutions | SMC Diode Solutions | SMC Diode Solutions |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MOSFET SILICON CARBIDE SIC 1200V | MOSFET SILICON CARBIDE SIC 1200V | MOSFET SILICON CARBIDE SIC 1200V | MOSFET SILICON CARBIDE SIC 1200V |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Bulk | Tube |
