S501-2.5-R
lmages are for reference only.S501-2.5-R
FUSE CERAMIC 2.5A 250VAC 5X20MM
Datasheet5mm x 20mm
44,714 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
2.5 A 250 V AC DC Fuse Cartridge, Ceramic Requires Holder 5mm x 20mm
S501-2.5-R
| Category | Circuit Protection - Fuses - |
| Manufacturer | Eaton - Electronics Division |
| Series | S501 |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Mounting Type | Requires Holder |
| Fuse Type | Cartridge, Ceramic |
| Current Rating (Amps) | 2.5 A |
| Voltage Rating - AC | 250 V |
| Voltage Rating - DC | - |
| Response Time | Fast Blow |
| Package / Case | 5mm x 20mm |
| Breaking Capacity @ Rated Voltage | 1.5kA |
| Melting I²t | 3.9 |
| Approval Agency | BSI, CCC, CSA, cURus, IMQ, MITI/JET, SEMKO, VDE |
| Operating Temperature | - |
| Color | - |
| Size / Dimension | 0.205" Dia x 0.787" L (5.20mm x 20.00mm) |
| Base Product Number | - |
| DC Cold Resistance | 0.053 Ohms |
| Product Attribute |  |
 |
 |
 |
| Part Number | S501-1-R | S501-1.25-R | S501-1.6-R | S501-100-R |
| Manufacturer | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | FUSE CERAMIC 1A 250VAC 5X20MM | FUSE CERAMIC 1.25A 250VAC 5X20MM | FUSE CERAMIC 1.6A 250VAC 5X20MM | FUSE CERAMIC 100MA 250VAC 5X20MM |
| Series | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division | Eaton - Electronics Division |
| Packaging | Bulk | Bulk | Bulk | Bulk |
