S6E1C12B0AGN20000
lmages are for reference only.S6E1C12B0AGN20000
IC MCU 32BIT 128KB FLASH 32QFN
Datasheet32-WFQFN Exposed Pad
47,034 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
ARM® Cortex®-M0+ FM0+ S6E1C1 Microcontroller IC 32-Bit Single-Core 40MHz 128KB (128K x 8) FLASH 32-QFN (5x5)
S6E1C12B0AGN20000
| Category | Integrated Circuits (ICs) - Embedded - Microcontrollers |
| Manufacturer | Infineon Technologies |
| Series | FM0+ S6E1C1 |
| Packaging | Tray |
| RoHS Status | ROHS3 Compliant |
| Core Processor | ARM® Cortex®-M0+ |
| Core Size | 32-Bit Single-Core |
| Speed | 40MHz |
| Connectivity | CSIO, I2C, LINbus, SmartCard, UART/USART |
| Peripherals | I2S, LVD, POR, PWM, WDT |
| Number of I/O | 24 |
| Program Memory Size | 128KB (128K x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| RAM Size | 16K x 8 |
| Voltage - Supply (Vcc/Vdd) | 1.65V ~ 3.6V |
| Data Converters | A/D 6x12b |
| Oscillator Type | Internal |
| Operating Temperature | -40°C ~ 105°C (TA) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 32-QFN (5x5) |
| Package / Case | 32-WFQFN Exposed Pad |
| Base Product Number | S6E1C12 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | S6E1C12B0AGP20000 | S6E1C12C0AGN20000 | S6E1C12C0AGV20000 | S6E1C12D0AGN20000 |
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC MCU 32BIT 128KB FLASH 32LQFP | IC MCU 32BIT 128KB FLASH 48QFN | IC MCU 32BIT 128KB FLASH 48LQFP | IC MCU 32BIT 128KB FLASH 64QFN |
| Series | Infineon Technologies | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| Packaging | Tray | Tray | Tray | Tray |
