SCC100AN
lmages are for reference only.SCC100AN
SENSOR 100PSIA 0.19" .225V
Datasheet4-SIP Module
90,860 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Pressure Sensor 100PSI (689.48kPa) Absolute Male - 0.19" (4.8mm) Tube, Dual 85 mV ~ 225 mV 4-SIP Module
SCC100AN
| Category | Sensors, Transducers - Pressure Sensors-Transducers - |
| Manufacturer | Honeywell Sensing and Productivity Solutions |
| Series | SCC |
| Packaging | Bulk |
| RoHS Status | RoHS Compliant |
| Base Product Number | - |
| Applications | Board Mount |
| Pressure Type | Absolute |
| Operating Pressure | 100PSI (689.48kPa) |
| Output Type | Wheatstone Bridge |
| Output | 85 mV ~ 225 mV |
| Accuracy | ±0.5% |
| Voltage - Supply | - |
| Port Size | Male - 0.19" (4.8mm) Tube, Dual |
| Port Style | Barbed |
| Features | Temperature Compensated |
| Termination Style | PC Pin |
| Maximum Pressure | 150PSI (1034.21kPa) |
| Operating Temperature | -40°C ~ 85°C |
| Mounting Type | Through Hole |
| Package / Case | 4-SIP Module |
| Supplier Device Package | - |
| Grade | - |
| Qualification | - |
| Product Attribute | |
|
|
|
| Part Number | SCC100A | SCC100A | SCC100ASMT | SCC100D |
| Manufacturer | Honeywell Sensing and Productivity Solutions | Honeywell Sensing and Productivity Solutions | Honeywell Sensing and Productivity Solutions | Honeywell Sensing and Productivity Solutions |
| RoHS Status | RoHS Compliant | RoHS Compliant | RoHS Compliant | RoHS Compliant |
| Description | SENSOR 100PSIA .225V | SENSOR 100PSIA .225V | SENSOR 100PSIA .225V | SENSOR 100PSID .225V BUTTON |
| Series | SCC | SCC | SCC SMT | SCC |
| Packaging | Bulk | Bulk | Bulk | Bulk |
