Product CatalogPart Number
SCH114-271
Manufacturer
Signal TransformerDescription
FIXED IND 270UH 680MA 927MOHM SM
Datasheet
DatasheetPackage
Nonstandard
In Stock
48,260 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
SCH114-271
SCH114-271
lmages are for reference only.Payment Methods
Delivery Services
270 µH Unshielded Wirewound Inductor 680 mA 927mOhm Max Nonstandard
Quick Inquiry
SCH114-271
Specifications
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Signal Transformer |
| Series | SCH114 |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Type | Wirewound |
| Material - Core | - |
| Inductance | 270 µH |
| Tolerance | ±10% |
| Current Rating (Amps) | 680 mA |
| Current - Saturation (Isat) | 720mA |
| Shielding | Unshielded |
| DC Resistance (DCR) | 927mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -40°C ~ 125°C |
| Inductance Frequency - Test | 100 kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.409" L x 0.409" W (10.40mm x 10.40mm) |
| Height - Seated (Max) | 0.193" (4.90mm) |
| Base Product Number | - |
