SG2842DM
lmages are for reference only.SG2842DM
IC OFFLINE SWITCH FLYBACK 8SOIC
Datasheet8-SOIC (0.154", 3.90mm Width)
44,050 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Converter Offline Flyback Topology 100Hz ~ 500kHz 8-SOIC
SG2842DM
| Category | Integrated Circuits (ICs) - Power Management PMIC - AC DC Converters-Offline Switches |
| Manufacturer | Microsemi Corporation |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS Compliant |
| Output Isolation | Isolated |
| Internal Switch(s) | No |
| Voltage - Breakdown | - |
| Topology | Flyback |
| Voltage - Supply (Vcc/Vdd) | 10V ~ 30V |
| Duty Cycle | 95% |
| Frequency - Switching | 100Hz ~ 500kHz |
| Power (Watts) | - |
| Fault Protection | Current Limiting |
| Control Features | Frequency Control |
| Operating Temperature | -25°C ~ 85°C (TA) |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
| Mounting Type | Surface Mount |
| Base Product Number | SG2842 |
| Voltage - Start Up | 16 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | SG2842M | SG2844DM | SG2844M | SGP400TZ-FS |
| Manufacturer | Microchip Technology | Microsemi Corporation | Microchip Technology | Fairchild Semiconductor |
| RoHS Status | ROHS3 Compliant | RoHS Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC OFFLINE SWITCH FLYBACK 8DIP | IC OFFLINE SWITCH 8SOIC | IC OFFLINE SWITCH 8DIP | 68KHZ PDSO6 |
| Series | - | - | - | - |
| Packaging | Tube | Bulk | Tube | Bulk |
