SGD02N120BUMA1
lmages are for reference only.SGD02N120BUMA1
IGBT NPT 1200V 6.2A TO252-3
DatasheetTO-252-3, DPAK (2 Leads + Tab), SC-63
31,553 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
IGBT NPT 1200 V 6.2 A 62 W Surface Mount PG-TO252-3-11
SGD02N120BUMA1
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | Infineon Technologies |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| IGBT Type | NPT |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
| Current - Collector (Ic) (Max) | 6.2 A |
| Current - Collector Pulsed (Icm) | 9.6 A |
| Vce(on) (Max) @ Vge, Ic | 3.6V @ 15V, 2A |
| Power - Max | 62 W |
| Switching Energy | 220µJ |
| Input Type | Standard |
| Gate Charge | 11 nC |
| Td (on/off) @ 25°C | 23ns/260ns |
| Test Condition | 800V, 2A, 91Ohm, 15V |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | TO-252-3, DPAK (2 Leads + Tab), SC-63 |
| Supplier Device Package | PG-TO252-3-11 |
| Reverse Recovery Time (trr) | - |
| Base Product Number | SGD02N |
| Product Attribute |  |
 |
|
 |
| Part Number | SGD02N60BUMA1 | SGD04N60BUMA1 | SGD04N60BUMA1 | SGD06N60BUMA1 |
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| RoHS Status | ROHS3 Compliant | |||
| Description | IGBT NPT 600V 6A TO252-3 | IGBT | IGBT 600V 9.4A 50W TO252-3 | IGBT 600V 12A 68W TO252-3 |
| Series | - | * | - | - |
| Packaging | Tape & Reel (TR) | Bulk | Tape & Reel (TR) | Tape & Reel (TR) |
