Product CatalogPart Number
SGP07N120XKSA1
Manufacturer
Infineon TechnologiesDescription
IGBT 1200V 16.5A 125W TO220
Datasheet
DatasheetPackage
TO-220-3
In Stock
80,135 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
SGP07N120XKSA1
SGP07N120XKSA1
lmages are for reference only.Payment Methods
Delivery Services
IGBT NPT 1200 V 16.5 A 125 W Through Hole PG-TO220-3-1
Quick Inquiry
SGP07N120XKSA1
Specifications
| Category | Discrete Semiconductor Products - Transistors - IGBTs |
| Manufacturer | Infineon Technologies |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| IGBT Type | NPT |
| Voltage - Collector Emitter Breakdown (Max) | 1200 V |
| Current - Collector (Ic) (Max) | 16.5 A |
| Current - Collector Pulsed (Icm) | 27 A |
| Vce(on) (Max) @ Vge, Ic | 3.6V @ 15V, 8A |
| Power - Max | 125 W |
| Switching Energy | 1mJ |
| Input Type | Standard |
| Gate Charge | 70 nC |
| Td (on/off) @ 25°C | 27ns/440ns |
| Test Condition | 800V, 8A, 47Ohm, 15V |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Grade | - |
| Qualification | - |
| Mounting Type | Through Hole |
| Package / Case | TO-220-3 |
| Supplier Device Package | PG-TO220-3-1 |
| Reverse Recovery Time (trr) | - |
| Base Product Number | SGP07N |
Parts with Similar Specifications
| Product Attribute |  |
|
 |
 |
| Part Number | SGP02N120XKSA1 | SGP02N60XKSA1 | SGP04N60XKSA1 | SGP06N60XKSA1 |
| Manufacturer | Infineon Technologies | Infineon Technologies | Infineon Technologies | Infineon Technologies |
| RoHS Status | ROHS3 Compliant | |||
| Description | IGBT 1200V 6.2A 62W TO220-3 | IGBT 600V 6A 30W TO220-3 | IGBT 600V 9.4A 50W TO220-3 | IGBT 600V 12A 68W TO220-3 |
| Series | - | - | - | - |
| Packaging | Tube | Tube | Tube | Tube |
