SH150T-0.68-39
lmages are for reference only.SH150T-0.68-39
FIXED IND 39UH 680MA 300 MOHM TH
DatasheetRadial, Horizontal - Corner Terminals
72,722 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
39 µH Unshielded Toroidal Inductor 680 mA 300mOhm Radial, Horizontal - Corner Terminals
SH150T-0.68-39
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Amgis, LLC |
| Series | SH150 |
| Packaging | Tray |
| RoHS Status | ROHS3 Compliant |
| Type | Toroidal |
| Material - Core | Iron Powder |
| Inductance | 39 µH |
| Tolerance | ±20% |
| Current Rating (Amps) | 680 mA |
| Current - Saturation (Isat) | - |
| Shielding | Unshielded |
| DC Resistance (DCR) | 300mOhm |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -40°C ~ 125°C |
| Inductance Frequency - Test | 10 kHz |
| Features | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Horizontal - Corner Terminals |
| Supplier Device Package | - |
| Size / Dimension | 0.433" L x 0.441" W (11.00mm x 11.20mm) |
| Height - Seated (Max) | 0.280" (7.10mm) |
| Base Product Number | - |
| Product Attribute |  |
|
|
|
| Part Number | SH150T-0.68-377 | SH150T-0.68-39 | SH150T-0.13-259 | SH150T-0.16-178 |
| Manufacturer | Amgis, LLC | Amgis, LLC | Amgis, LLC | Amgis, LLC |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | FIXED IND 377UH 680MA 1 OHM TH | FIXED IND 39UH 680MA 300 MOHM TH | FIXED IND 259UH 130MA 3.4 OHM TH | FIXED IND 178UH 160MA 2.8 OHM TH |
| Series | Amgis, LLC | Amgis, LLC | Amgis, LLC | Amgis, LLC |
| Packaging | Tray | Tray | Tray | Tray |
