SIA920DJ-T1-GE3
lmages are for reference only.SIA920DJ-T1-GE3
MOSFET 2N-CH 8V 4.5A PPAK8X8
DatasheetPowerPAK® SC-70-6 Dual
10,010 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Mosfet Array 8V 4.5A 7.8W Surface Mount PowerPAK® SC-70-6 Dual
SIA920DJ-T1-GE3
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Vishay Siliconix |
| Series | TrenchFET® |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Technology | MOSFET (Metal Oxide) |
| Configuration | 2 N-Channel (Dual) |
| FET Feature | Logic Level Gate |
| Drain to Source Voltage (Vdss) | 8V |
| Current - Continuous Drain (Id) @ 25°C | 4.5A |
| Rds On (Max) @ Id, Vgs | 27mOhm @ 5.3A, 4.5V |
| Vgs(th) (Max) @ Id | 700mV @ 250µA |
| Gate Charge (Qg) (Max) @ Vgs | 7.5nC @ 4.5V |
| Input Capacitance (Ciss) (Max) @ Vds | 470pF @ 4V |
| Power - Max | 7.8W |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | PowerPAK® SC-70-6 Dual |
| Supplier Device Package | PowerPAK® SC-70-6 Dual |
| Base Product Number | SIA920 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | SIA921EDJ-T1-GE3 | SIA921EDJ-T4-GE3 | SIA922EDJ-T1-GE3 | SIA922EDJ-T4-GE3 |
| Manufacturer | Vishay Siliconix | Vishay Siliconix | Vishay Siliconix | Vishay Siliconix |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | MOSFET 2P-CH 20V 4.5A PPAK8X8 | MOSFET 2P-CH 20V 4.5A PPAK8X8 | MOSFET 2N-CH 30V 4.5A PPAK8X8 | MOSFET 2N-CH 30V 4.4A PPAK8X8 |
| Series | TrenchFET® | TrenchFET® | TrenchFET® | TrenchFET® |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
