SIC1182KQ-TL
lmages are for reference only.SIC1182KQ-TL
DGT ISO 5KV 1CH GT DVR ESOP-R16B
Datasheet16-PowerSOIC (0.350", 8.89mm Width), 15 Leads
92,989 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
8A Gate Driver Magnetic Coupling 5000Vrms 1 Channel eSOP-R16B
SIC1182KQ-TL
| Category | Isolators - Isolators Gate Drivers - |
| Manufacturer | Power Integrations |
| Series | SCALE-iDriver™ |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Technology | Magnetic Coupling |
| Number of Channels | 1 |
| Voltage - Isolation | 5000Vrms |
| Common Mode Transient Immunity (Min) | 35kV/µs (Typ) |
| Propagation Delay tpLH / tpHL (Max) | 305ns, 325ns |
| Pulse Width Distortion (Max) | - |
| Rise / Fall Time (Typ) | 475ns, 447ns |
| Current - Output High, Low | 7.8A, 7.3A |
| Current - Peak Output | 8A |
| Voltage - Forward (Vf) (Typ) | - |
| Voltage - Output Supply | 18V ~ 28V |
| Grade | - |
| Qualification | - |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | 16-PowerSOIC (0.350", 8.89mm Width), 15 Leads |
| Supplier Device Package | eSOP-R16B |
| Approval Agency | CSA, UL1577, VDE |
| Base Product Number | SIC1182 |
| Current - DC Forward (If) (Max) | - |
| Product Attribute | |
|
|
 |
| Part Number | SIC1182KQ | SIC1181KQ | SIC1181KQ-TL | SIC1182K |
| Manufacturer | Power Integrations | Power Integrations | Power Integrations | Power Integrations |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | DGT ISO 5KV 1CH GT DVR ESOP-R16B | DGT ISO 5KV 1CH GT DVR ESOP-R16B | DGT ISO 5KV 1CH GT DVR ESOP-R16B | DGT ISO 5KV 1CH GT DVR ESOP-R16B |
| Series | Power Integrations | Power Integrations | Power Integrations | Power Integrations |
| Packaging | Tube | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tube |
