SM2011A-2R2MHF
lmages are for reference only.SM2011A-2R2MHF
MOLDED INDUCTOR 2.2UH 24.5M 7.5
DatasheetNonstandard
57,609 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
2.2 µH Unshielded Molded Inductor 7 A 28mOhm Max Nonstandard
SM2011A-2R2MHF
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | ITG Electronics, Inc. |
| Series | SM2011A |
| Packaging | Bulk |
| RoHS Status | RoHS Compliant |
| Type | Molded |
| Material - Core | - |
| Inductance | 2.2 µH |
| Tolerance | ±20% |
| Current Rating (Amps) | 7 A |
| Current - Saturation (Isat) | 5.2A |
| Shielding | Unshielded |
| DC Resistance (DCR) | 28mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -55°C ~ 125°C |
| Inductance Frequency - Test | 100 kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.213" L x 0.205" W (5.40mm x 5.20mm) |
| Height - Seated (Max) | 0.118" (3.00mm) |
| Base Product Number | - |
| Product Attribute | |
 |
|
|
| Part Number | SM2011A-2R2MHF | SM2011A-1R0MHF | SM2011A-1R5MHF | SM2011A-4R7MHF |
| Manufacturer | ITG Electronics, Inc. | ITG Electronics, Inc. | ITG Electronics, Inc. | ITG Electronics, Inc. |
| RoHS Status | RoHS Compliant | RoHS Compliant | RoHS Compliant | RoHS Compliant |
| Description | MOLDED INDUCTOR 2.2UH 24.5M 7.5 | MOLDED INDUCTOR 1UH 11.2M 11A | MOLDED INDUCTOR1.5UH13.75M10.5A | MOLDED INDUCTOR4.7UH 52.2M 5.5A |
| Series | ITG Electronics, Inc. | ITG Electronics, Inc. | ITG Electronics, Inc. | ITG Electronics, Inc. |
| Packaging | Bulk | Bulk | Bulk | Bulk |
