SMBT3904SE6327HTSA1
lmages are for reference only.SMBT3904SE6327HTSA1
TRANS 2NPN 40V 0.2A PG-SOT363-PO
Datasheet6-VSSOP, SC-88, SOT-363
29,665 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Bipolar (BJT) Transistor Array 2 NPN (Dual) 40V 200mA 300MHz 330mW Surface Mount PG-SOT363-PO
SMBT3904SE6327HTSA1
| Category | Discrete Semiconductor Products - Transistors - Bipolar BJT |
| Manufacturer | Infineon Technologies |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | |
| Transistor Type | 2 NPN (Dual) |
| Current - Collector (Ic) (Max) | 200mA |
| Voltage - Collector Emitter Breakdown (Max) | 40V |
| Vce Saturation (Max) @ Ib, Ic | 300mV @ 5mA, 50mA |
| Current - Collector Cutoff (Max) | 50nA (ICBO) |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 100 @ 10mA, 1V |
| Power - Max | 330mW |
| Frequency - Transition | 300MHz |
| Operating Temperature | 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 6-VSSOP, SC-88, SOT-363 |
| Supplier Device Package | PG-SOT363-PO |
| Base Product Number | SMBT 3904 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
|
 |
| Part Number | SMBT3904SH6327XTSA1 | SMBT 3904U E6327 | SMBT2227A-TP | SMBT2907A-TP |
| Manufacturer | Infineon Technologies | Infineon Technologies | Micro Commercial Co | Micro Commercial Co |
| RoHS Status | ROHS3 Compliant | |||
| Description | TRANS 2NPN 40V 0.2A PG-SOT363-PO | TRANS 2NPN 40V 200MA PG-SC74-6 | TRANS NPN/PNP 40V/60V SOT-23-6L | TRANS 2PNP 60V 600MA SOT-23-6L |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Bulk | Bulk |
