SMDJ16A
Manufacturer
NextGen ComponentsDescription
TVS Diode 3000W 16V UNI SMD
Datasheet
DatasheetPackage
DO-214AB, SMC
In Stock
69,696 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
SMDJ16A
SMDJ16A
lmages are for reference only.Payment Methods
Delivery Services
26V Clamp 115.4A Ipp Tvs Diode Surface Mount SMC (DO-214AB)
Quick Inquiry
SMDJ16A
Specifications
| Category | Circuit Protection - Transient Voltage Suppressors TVS - TVS Diodes |
| Manufacturer | NextGen Components |
| Series | SMDJ |
| Packaging | Tape & Reel (TR) |
| RoHS Status | RoHS Compliant |
| Type | Zener |
| Bidirectional Channels | - |
| Voltage - Reverse Standoff (Typ) | 16V |
| Voltage - Breakdown (Min) | 17.8V |
| Voltage - Clamping (Max) @ Ipp | 26V |
| Current - Peak Pulse (10/1000µs) | 115.4A |
| Power - Peak Pulse | 3000W (3kW) |
| Power Line Protection | No |
| Applications | General Purpose |
| Capacitance @ Frequency | - |
| Operating Temperature | -65°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | DO-214AB, SMC |
| Supplier Device Package | SMC (DO-214AB) |
| Base Product Number | - |
| Unidirectional Channels | 1 |
| Grade | - |
| Qualification | - |
