SMF17CA
lmages are for reference only.SMF17CA
SURFACE MOUNT UNI/BI-DIRECTIONAL
DatasheetSOD-123F
18,957 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
27.6V Clamp 7.2A Ipp Tvs Diode Surface Mount SOD-123FL
SMF17CA
| Category | Circuit Protection - Transient Voltage Suppressors TVS - TVS Diodes |
| Manufacturer | HY Electronic (Cayman) Limited |
| Series | SMF |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Type | Zener |
| Bidirectional Channels | 1 |
| Voltage - Reverse Standoff (Typ) | 17V |
| Voltage - Breakdown (Min) | 18.9V |
| Voltage - Clamping (Max) @ Ipp | 27.6V |
| Current - Peak Pulse (10/1000µs) | 7.2A |
| Power - Peak Pulse | 200W |
| Power Line Protection | No |
| Applications | General Purpose |
| Capacitance @ Frequency | - |
| Operating Temperature | -55°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | SOD-123F |
| Supplier Device Package | SOD-123FL |
| Base Product Number | - |
| Unidirectional Channels | - |
| Grade | - |
| Qualification | - |
| Product Attribute | |
|
|
 |
| Part Number | SMF17CA | SMF17CA | SMF17CA | SMF17CA-HF |
| Manufacturer | Meritek | Diotec Semiconductor | Littelfuse Inc. | Comchip Technology |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | RoHS Compliant | |
| Description | TVS DIODE 17VWM 27.6VC | TVS DIODE 17VWM 27.6VC SOD-123FL | TVS SOD123FL 17V 200W BIDIR | DIODE TVS 200W 17V BI-DIRECTIONA |
| Series | Meritek | Diotec Semiconductor | Littelfuse Inc. | Comchip Technology |
| Packaging | Strip | Bulk | Tape & Reel (TR) | Tape & Reel (TR) |
