SML-D14MWT86A
lmages are for reference only.SML-D14MWT86A
LED YLW-GRN CLEAR 1608 SMD
Datasheet0603 (1608 Metric)
23,299 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Yellow-Green 571nm LED Indication - Discrete 2.1V 0603 (1608 Metric)
SML-D14MWT86A
| Category | Optoelectronics - LED Indication Discrete - |
| Manufacturer | Rohm Semiconductor |
| Series | SML-D14(A) |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Color | Yellow-Green |
| Configuration | - |
| Lens Color | Colorless |
| Lens Transparency | Clear |
| Millicandela Rating | 60mcd |
| Lens Style | Rectangle with Flat Top |
| Lens Size | 1.20mm x 0.80mm |
| Voltage - Forward (Vf) (Typ) | 2.1V |
| Current - Test | 20mA |
| Viewing Angle | - |
| Mounting Type | Surface Mount |
| Wavelength - Dominant | 571nm |
| Wavelength - Peak | - |
| Features | - |
| Package / Case | 0603 (1608 Metric) |
| Supplier Device Package | 1608 (0603) |
| Size / Dimension | 1.60mm L x 0.80mm W |
| Height (Max) | 0.65mm |
| Base Product Number | SML-D14 |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | SML-D14MWT86C | SML-D14DWT86A | SML-D14DWT86C | SML-D14U2WT86A |
| Manufacturer | Rohm Semiconductor | Rohm Semiconductor | Rohm Semiconductor | Rohm Semiconductor |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | LED YLW-GRN 1608 SMD | LED ORANGE CLEAR 1608 SMD | LED ORANGE 1608 SMD | LED RED CLEAR 1608 SMD |
| Series | Rohm Semiconductor | Rohm Semiconductor | Rohm Semiconductor | Rohm Semiconductor |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
