SPFC-RM10-75
lmages are for reference only.SPFC-RM10-75
PWR FACTOR COR RM10 PCB 75W
DatasheetRadial, Vertical, 14 Leads
20,957 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
650 µH Shielded Wirewound Inductor 400 mA 480mOhm Max Radial, Vertical, 14 Leads
SPFC-RM10-75
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Signal Transformer |
| Series | SPFC |
| Packaging | Tray |
| RoHS Status | ROHS3 Compliant |
| Type | Wirewound |
| Material - Core | - |
| Inductance | 650 µH |
| Tolerance | ±10% |
| Current Rating (Amps) | 400 mA |
| Current - Saturation (Isat) | 3.9A |
| Shielding | Shielded |
| DC Resistance (DCR) | 480mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -40°C ~ 125°C |
| Inductance Frequency - Test | 100 kHz |
| Features | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Vertical, 14 Leads |
| Supplier Device Package | Radial, Vertical, 14 Leads |
| Size / Dimension | 1.220" L x 1.142" W (31.00mm x 29.00mm) |
| Height - Seated (Max) | 0.787" (20.00mm) |
| Base Product Number | - |
| Product Attribute | |
 |
|
 |
| Part Number | SPFC-RM10-75 | SPFC-RM10-100 | SPFC-RM10-100 | SPFC-RM10-150 |
| Manufacturer | Signal Transformer | Signal Transformer | Signal Transformer | Signal Transformer |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | PWR FACTOR COR RM10 PCB 75W | PWR FACTOR COR RM10 PCB 100W | PWR FACTOR COR RM10 PCB 100W | PWR FACTOR COR RM10 PCB 150W |
| Series | Signal Transformer | Signal Transformer | Signal Transformer | Signal Transformer |
| Packaging | Tray | Tray | Tray | Tray |
