Product CatalogPart Number
SPM6530T-220M-HZ
Manufacturer
TDK CorporationDescription
FIXED IND 22UH 2.6A 200.2MOHM SM
Datasheet
DatasheetPackage
Nonstandard
In Stock
74,275 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
SPM6530T-220M-HZ
SPM6530T-220M-HZ
lmages are for reference only.Payment Methods
Delivery Services
22 µH Shielded Drum Core, Wirewound Inductor 2.6 A 200.2mOhm Max Nonstandard
Quick Inquiry
SPM6530T-220M-HZ
Specifications
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | TDK Corporation |
| Series | SPM-HZ |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Type | Drum Core, Wirewound |
| Material - Core | Metal |
| Inductance | 22 µH |
| Tolerance | ±20% |
| Current Rating (Amps) | 2.6 A |
| Current - Saturation (Isat) | 1.7A |
| Shielding | Shielded |
| DC Resistance (DCR) | 200.2mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | AEC-Q200 |
| Operating Temperature | -40°C ~ 125°C |
| Inductance Frequency - Test | 100 kHz |
| Features | - |
| Mounting Type | Surface Mount |
| Package / Case | Nonstandard |
| Supplier Device Package | - |
| Size / Dimension | 0.280" L x 0.256" W (7.10mm x 6.50mm) |
| Height - Seated (Max) | 0.118" (3.00mm) |
| Base Product Number | - |
