SQ7414AEN-T1_GE3
lmages are for reference only.SQ7414AEN-T1_GE3
MOSFET N-CH 60V 16A PPAK1212-8
DatasheetPowerPAK® 1212-8
90,015 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 60 V 16A (Tc) 62W (Tc) Surface Mount PowerPAK® 1212-8
SQ7414AEN-T1_GE3
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Vishay Siliconix |
| Series | TrenchFET® |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 60 V |
| Current - Continuous Drain (Id) @ 25°C | 16A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Rds On (Max) @ Id, Vgs | 26mOhm @ 5.7A, 10V |
| Vgs(th) (Max) @ Id | 2.5V @ 250µA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 980 pF @ 30 V |
| FET Feature | - |
| Power Dissipation (Max) | 62W (Tc) |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | PowerPAK® 1212-8 |
| Package / Case | PowerPAK® 1212-8 |
| Base Product Number | SQ7414 |
| Gate Charge (Qg) (Max) @ Vgs | 24 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
 |
|
| Part Number | SQ7414AEN-T1_BE3 | SQ7414AENW-T1_GE3 | SQ7414CENW-T1_GE3 | SFP9Z34 |
| Manufacturer | Vishay Siliconix | Vishay Siliconix | Vishay Siliconix | onsemi |
| RoHS Status | ROHS3 Compliant | |||
| Description | MOSFET N-CH 60V 5.6A PPAK 1212-8 | MOSFET N-CH 60V 18A PPAK1212-8 | MOSFET N-CH 60V 18A PPAK1212-8W | MOSFET P-CH 60V 18A TO220-3 |
| Series | TrenchFET® | - | TrenchFET® | - |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tube |
