SRV05-4
lmages are for reference only.SRV05-4
TVS DIODE 5V VBR MIN 6V SOT-23
DatasheetSOT-23-6
38,493 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
15V Clamp 4A (8/20µs) Ipp Tvs Diode Surface Mount SOT23-6L
SRV05-4
| Category | Circuit Protection - Transient Voltage Suppressors TVS - TVS Diodes |
| Manufacturer | ANBON SEMICONDUCTOR (INT'L) LIMITED |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Type | Steering (Rail to Rail) |
| Bidirectional Channels | - |
| Voltage - Reverse Standoff (Typ) | 5V (Max) |
| Voltage - Breakdown (Min) | 6V |
| Voltage - Clamping (Max) @ Ipp | 15V |
| Current - Peak Pulse (10/1000µs) | 4A (8/20µs) |
| Power - Peak Pulse | 60W |
| Power Line Protection | Yes |
| Applications | General Purpose |
| Capacitance @ Frequency | 1pF @ 1MHz |
| Operating Temperature | -55°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | SOT-23-6 |
| Supplier Device Package | SOT23-6L |
| Base Product Number | - |
| Unidirectional Channels | 4 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
 |
|
| Part Number | SRV05-4 | SRV05-4-TP | SRV05-4.TCT | SRV05-4.TCT |
| Manufacturer | EVVO | Micro Commercial Co | Semtech Corporation | UMW |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | TVS DIODE 5V VBR MIN 6V SOT-23 | DIODE ESD PROT 5V | TVS DIODE 5VWM 17.5VC SOT23-6 | SOT23-6 |
| Series | EVVO | Micro Commercial Co | Semtech Corporation | UMW |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
