SS49
lmages are for reference only.SS49
SENSOR HALL EFFECT ANALOG 3SIP
Datasheet3-SIP
62,804 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Hall Effect Sensor Single Axis
SS49
| Category | Sensors, Transducers - Magnetic Sensors - Linear-Compass ICs |
| Manufacturer | Honeywell Sensing and Productivity Solutions |
| Series | SS49 |
| Packaging | Bulk |
| RoHS Status | RoHS Compliant |
| Technology | Hall Effect |
| Axis | Single |
| Output Type | Analog Voltage |
| Sensing Range | - |
| Voltage - Supply | 4V ~ 10V |
| Current - Supply (Max) | 4mA (Typ) |
| Current - Output (Max) | 20mA |
| Resolution | - |
| Bandwidth | - |
| Operating Temperature | -40°C ~ 100°C |
| Grade | - |
| Qualification | - |
| Features | - |
| Supplier Device Package | - |
| Mounting Type | Through Hole |
| Package / Case | 3-SIP |
| Base Product Number | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | SS491B | SS494B | SS494B-S | SS494B-SP |
| Manufacturer | Honeywell Sensing and Productivity Solutions | Honeywell Sensing and Productivity Solutions | Honeywell Sensing and Productivity Solutions | Honeywell Sensing and Productivity Solutions |
| RoHS Status | RoHS Compliant | RoHS Compliant | RoHS Compliant | |
| Description | SENSOR HALL EFFECT ANALOG TO92-3 | SENSOR HALL EFFECT ANALOG 3SIP | SOLID STATE SENSOR | SENSOR HALL EFFECT ANALOG 3-SMD |
| Series | - | SS494 | * | SS494 |
| Packaging | Bulk | Bulk | Bulk | Tape & Reel (TR) |
