SSM6J771G,LF
lmages are for reference only.SSM6J771G,LF
MOSFET P-CH 20V 5A 6WCSP
Datasheet6-UFBGA, WLCSP
60,514 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
P-Channel 20 V 5A (Ta) 1.2W (Ta) Surface Mount
SSM6J771G,LF
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Toshiba Semiconductor and Storage |
| Series | U-MOSVI |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| FET Type | P-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 20 V |
| Current - Continuous Drain (Id) @ 25°C | 5A (Ta) |
| Drive Voltage (Max Rds On, Min Rds On) | 2.5V, 8.5V |
| Rds On (Max) @ Id, Vgs | 31mOhm @ 3A, 8.5V |
| Vgs(th) (Max) @ Id | 1.2V @ 1mA |
| Vgs (Max) | ±12V |
| Input Capacitance (Ciss) (Max) @ Vds | 870 pF @ 10 V |
| FET Feature | - |
| Power Dissipation (Max) | 1.2W (Ta) |
| Operating Temperature | 150°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | - |
| Package / Case | 6-UFBGA, WLCSP |
| Base Product Number | SSM6J771 |
| Gate Charge (Qg) (Max) @ Vgs | 9.8 nC @ 4.5 V |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
|
|
| Part Number | SS07N70AKMA1 | SSF02N15 | SSF0910S | SSF10N80A |
| Manufacturer | Infineon Technologies | Good-Ark Semiconductor | Good-Ark Semiconductor | Fairchild Semiconductor |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | RoHS non-compliant | |
| Description | MOSFET N-CH | MOSFET, N-CH, SINGLE, 1.4A, 150V | MOSFET, N-CH, SINGLE, 2.0A, 100V | N-CHANNEL POWER MOSFET |
| Series | - | - | - | - |
| Packaging | Bulk | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Bulk |
