SWC-1.4-220
lmages are for reference only.SWC-1.4-220
FIXED IND 220UH 1.4A 140 MOHM TH
DatasheetRadial, Vertical (Open)
58,865 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
220 µH Unshielded Toroidal Inductor 1.4 A 140mOhm Max Radial, Vertical (Open)
SWC-1.4-220
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Amgis, LLC |
| Series | SW |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Type | Toroidal |
| Material - Core | Iron Powder |
| Inductance | 220 µH |
| Tolerance | ±20% |
| Current Rating (Amps) | 1.4 A |
| Current - Saturation (Isat) | - |
| Shielding | Unshielded |
| DC Resistance (DCR) | 140mOhm Max |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -40°C ~ 125°C |
| Inductance Frequency - Test | 10 kHz |
| Features | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Vertical (Open) |
| Supplier Device Package | - |
| Size / Dimension | 0.827" L x 0.449" W (21.00mm x 11.40mm) |
| Height - Seated (Max) | 0.937" (23.80mm) |
| Base Product Number | - |
| Product Attribute |  |
|
|
 |
| Part Number | SWC-1.4-176 | SWC-1.3-680 | SWC-1.50-250 | SWC-1.81-168 |
| Manufacturer | Amgis, LLC | Amgis, LLC | Amgis, LLC | Amgis, LLC |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | INDUCTOR 176UH 1.4A 50KHZ CLP | FIXED IND 680UH 1.3A 200 MOHM TH | FIXED IND 250UH 1.5A 230 MOHM TH | FIXED IND 168UH 1.81A 180MOHM TH |
| Series | Amgis, LLC | Amgis, LLC | Amgis, LLC | Amgis, LLC |
| Packaging | Tray | Bulk | Bulk | Bulk |
