SWT-0.84-26
lmages are for reference only.SWT-0.84-26
FIXED IND 26UH 840MA 200 MOHM TH
DatasheetRadial, Horizontal (Open)
56,311 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
26 µH Unshielded Toroidal Inductor 840 mA 200mOhm Radial, Horizontal (Open)
SWT-0.84-26
| Category | Inductors, Coils, Chokes - Fixed Inductors - |
| Manufacturer | Amgis, LLC |
| Series | SW |
| Packaging | Bulk |
| RoHS Status | ROHS3 Compliant |
| Type | Toroidal |
| Material - Core | Iron Powder |
| Inductance | 26 µH |
| Tolerance | ±20% |
| Current Rating (Amps) | 840 mA |
| Current - Saturation (Isat) | - |
| Shielding | Unshielded |
| DC Resistance (DCR) | 200mOhm |
| Q @ Freq | - |
| Frequency - Self Resonant | - |
| Ratings | - |
| Operating Temperature | -40°C ~ 125°C |
| Inductance Frequency - Test | 10 kHz |
| Features | - |
| Mounting Type | Through Hole |
| Package / Case | Radial, Horizontal (Open) |
| Supplier Device Package | - |
| Size / Dimension | 0.339" L x 0.339" W (8.60mm x 8.60mm) |
| Height - Seated (Max) | 0.287" (7.30mm) |
| Base Product Number | - |
| Product Attribute | |
 |
|
|
| Part Number | SWT-0.84-26 | SWT-0.13-259 | SWT-0.16-178 | SWT-0.2-374 |
| Manufacturer | Amgis, LLC | Amgis, LLC | Amgis, LLC | Amgis, LLC |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | FIXED IND 26UH 840MA 200 MOHM TH | FIXED IND 259UH 130MA 3.4 OHM TH | FIXED IND 178UH 160MA 2.8 OHM TH | FIXED IND 374UH 200MA 2.7 OHM TH |
| Series | Amgis, LLC | Amgis, LLC | Amgis, LLC | Amgis, LLC |
| Packaging | Bulk | Bulk | Bulk | Tray |
