TB6560AFG,8
lmages are for reference only.TB6560AFG,8
IC MOTOR DRIVER PAR 64HQFP
Datasheet64-TQFP Exposed Pad
42,568 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Bipolar Motor Driver Parallel 64-HQFP (10x10)
TB6560AFG,8
| Category | Integrated Circuits (ICs) - Power Management PMIC - Motor Drivers-Controllers |
| Manufacturer | Toshiba Semiconductor and Storage |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Motor Type - Stepper | Bipolar |
| Motor Type - AC, DC | - |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Output Configuration | Half Bridge (4) |
| Interface | Parallel |
| Technology | - |
| Step Resolution | - |
| Applications | General Purpose |
| Current - Output | 1.5A |
| Voltage - Supply | 4.5V ~ 5.5V |
| Voltage - Load | 4.5V ~ 34V |
| Operating Temperature | -30°C ~ 85°C |
| Mounting Type | Surface Mount |
| Package / Case | 64-TQFP Exposed Pad |
| Supplier Device Package | 64-HQFP (10x10) |
| Base Product Number | TB6560 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
|
 |
| Part Number | TB6560AFG,8 | TB6560AFTG,8,EL | TB6560AFTG,8,EL | TB6560AFTG,C8,EL |
| Manufacturer | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage |
| RoHS Status | ROHS3 Compliant | RoHS Compliant | RoHS Compliant | ROHS3 Compliant |
| Description | IC MOTOR DRIVER PAR 64HQFP | IC MTR DRVR BIPLR 4.5-5.5V 48QFN | IC MTR DRVR BIPLR 4.5-5.5V 48QFN | STEPPING MOTOR DRIVER, 40V/3.5A, |
| Series | - | - | - | - |
| Packaging | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
