TB6641FG,8,EL
lmages are for reference only.TB6641FG,8,EL
IC MOTOR DRIVER 10V-45V 16SOP
Datasheet16-BSOP (0.252", 6.40mm Width) + 2 Heat Tabs
54,913 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Motor Driver Power MOSFET Parallel, PWM 16-HSOP
TB6641FG,8,EL
| Category | Integrated Circuits (ICs) - Power Management PMIC - Motor Drivers-Controllers |
| Manufacturer | Toshiba Semiconductor and Storage |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Motor Type - Stepper | - |
| Motor Type - AC, DC | Brushed DC |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Output Configuration | Half Bridge (2) |
| Interface | Parallel, PWM |
| Technology | Power MOSFET |
| Step Resolution | - |
| Applications | General Purpose |
| Current - Output | 1.5A |
| Voltage - Supply | 10V ~ 45V |
| Voltage - Load | 10V ~ 45V |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Surface Mount |
| Package / Case | 16-BSOP (0.252", 6.40mm Width) + 2 Heat Tabs |
| Supplier Device Package | 16-HSOP |
| Base Product Number | TB6641 |
| Grade | - |
| Qualification | - |
| Product Attribute | |
 |
|
 |
| Part Number | TB6641FG,8,EL | TB6641FTG,8,EL | TB6641FTG,8,EL | TB62206FG,EL |
| Manufacturer | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | |
| Description | IC MOTOR DRIVER 10V-45V 16SOP | IC MOTOR DRIVER 10V-45V 32VQFN | IC MOTOR DRIVER 10V-45V 32VQFN | IC MTR DRV BIPLR 4.5-5.5V 20HSOP |
| Series | - | - | - | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
