TC7WH02FK(TE85L)
lmages are for reference only.TC7WH02FK(TE85L)
IC GATE NOR 2CH 2-INP US8
Datasheet8-VFSOP (0.091", 2.30mm Width)
42,558 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
NOR Gate IC 2 Channel 8-SSOP
TC7WH02FK(TE85L)
| Category | Integrated Circuits (ICs) - Logic - Gates and Inverters |
| Manufacturer | Toshiba Semiconductor and Storage |
| Series | 7WH |
| Packaging | Cut Tape (CT) |
| RoHS Status | RoHS non-compliant |
| Base Product Number | 7WH02 |
| Logic Type | NOR Gate |
| Number of Circuits | 2 |
| Number of Inputs | 2 |
| Features | - |
| Voltage - Supply | 2V ~ 5.5V |
| Current - Quiescent (Max) | 2 μA |
| Current - Output High, Low | 8mA, 8mA |
| Input Logic Level - Low | 0.5V |
| Input Logic Level - High | 1.5V |
| Max Propagation Delay @ V, Max CL | 7.5ns @ 5V, 50pF |
| Operating Temperature | -40＜C ~ 85＜C |
| Mounting Type | Surface Mount |
| Supplier Device Package | 8-SSOP |
| Package / Case | 8-VFSOP (0.091", 2.30mm Width) |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | TC7WH00FK,LJ(CT | TC7WH00FU,LJ(CT | TC7WH02FU,LJ(CT | TC7WH04FK,LJ(CT |
| Manufacturer | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC GATE NAND 2CH 4-INP 8SSOP | IC GATE NAND 2CH 2-INP 8SSOP | IC GATE NOR 2CH 2-INP SM8 | IC INVERTER 3CH 3-INP 8SSOP |
| Series | TC7WH | TC7WH | TC7WH | TC7WH |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
