TDA3661AT/N1,118
lmages are for reference only.TDA3661AT/N1,118
TDA3661 - IC VOLT REG ADJUSTABLE
Datasheet8-SOIC (0.154", 3.90mm Width)
21,352 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Linear Voltage Regulator IC Positive Adjustable 1 Output 100mA 8-SOIC
TDA3661AT/N1,118
| Category | Integrated Circuits (ICs) - Power Management PMIC - Voltage Regulators Linear-Low Drop Out LDO Regulators |
| Manufacturer | NXP Semiconductors |
| Series | - |
| Packaging | Bulk |
| RoHS Status | RoHS non-compliant |
| Output Configuration | Positive |
| Output Type | Adjustable |
| Number of Regulators | 1 |
| Voltage - Input (Max) | 45V |
| Voltage - Output (Min/Fixed) | 1.5V |
| Voltage - Output (Max) | 45V |
| Voltage Dropout (Max) | 0.3V @ 50mA |
| Current - Output | 100mA |
| Current - Quiescent (Iq) | 30 µA |
| PSRR | 60dB (120Hz) |
| Control Features | - |
| Protection Features | Over Current, Over Temperature, Reverse Polarity, Short Circuit, Transient Voltage |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Grade | - |
| Qualification | - |
| Mounting Type | Surface Mount |
| Package / Case | 8-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 8-SOIC |
| Base Product Number | - |
| Current - Supply (Max) | 2.5 mA |
| Product Attribute |  |
 |
 |
 |
| Part Number | TDA3663/N1,135 | TDA3664/N1,135 | TDA3664AT/N1,118 | TDA3664AT/N1/N,118 |
| Manufacturer | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC REG LINEAR 3.3V 100MA SOT223 | IC REG LINEAR 5V 100MA SOT223 | IC REG LINEAR 5V 100MA 8SO | IC REG LINEAR 5V 100MA 8SO |
| Series | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. | NXP USA Inc. |
| Packaging | Tape & Reel (TR) | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR) |
