TIL199ASMT&R
lmages are for reference only.TIL199ASMT&R
16PIN DARLINGTON OUTPUT, QUAD OP
Datasheet16-SMD, Gull Wing
26,325 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Optoisolator Darlington Output 5300Vrms 4 Channel 16-SMD
TIL199ASMT&R
| Category | Isolators - Optoisolators - Transistor-Photovoltaic Output Optoisolators |
| Manufacturer | Isocom Components 2004 LTD |
| Series | TIL199A |
| Packaging | Tape & Reel (TR) |
| RoHS Status | ROHS3 Compliant |
| Number of Channels | 4 |
| Voltage - Isolation | 5300Vrms |
| Current Transfer Ratio (Min) | 1000% @ 2mA |
| Current Transfer Ratio (Max) | 7500% @ 2mA |
| Turn On / Turn Off Time (Typ) | - |
| Rise / Fall Time (Typ) | 100µs, 100µs |
| Input Type | DC |
| Output Type | Darlington |
| Voltage - Output (Max) | 35V |
| Current - Output / Channel | - |
| Voltage - Forward (Vf) (Typ) | 1.2V |
| Current - DC Forward (If) (Max) | 50 mA |
| Vce Saturation (Max) | 1V |
| Operating Temperature | -55°C ~ 100°C |
| Mounting Type | Surface Mount |
| Package / Case | 16-SMD, Gull Wing |
| Supplier Device Package | 16-SMD |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | TIL199ASM | TIL199 | TIL199A | TIL199AG |
| Manufacturer | Isocom Components 2004 LTD | Isocom Components 2004 LTD | Isocom Components 2004 LTD | Isocom Components 2004 LTD |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | 16PIN DARLINGTON OUTPUT, QUAD OP | 16PIN DARLINGTON OUTPUT, QUAD OP | 16PIN DARLINGTON OUTPUT, QUAD OP | 16PIN DARLINGTON OUTPUT, QUAD OP |
| Series | TIL199 | TIL199 | TIL199 | TIL199 |
| Packaging | Tube | Tube | Tube | Tube |
