Product CatalogPart Number
TL494GD
Manufacturer
TAEJINDescription
IC REG CTRLR MULT TOP SOP-16
Datasheet
DatasheetPackage
16-SOIC (0.154", 3.90mm Width)
In Stock
16,245 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
TL494GD
TL494GD
lmages are for reference only.Payment Methods
Delivery Services
Buck Regulator Positive Output Step-Down DC-DC Controller IC 16-SOP
Quick Inquiry
TL494GD
Specifications
| Category | Integrated Circuits (ICs) - Power Management PMIC - DC DC Switching Controllers |
| Manufacturer | TAEJIN |
| Series | - |
| Packaging | Tape & Reel (TR) |
| RoHS Status | RoHS Compliant |
| Output Type | Transistor Driver |
| Function | Step-Down |
| Output Configuration | Positive |
| Topology | Buck |
| Number of Outputs | 2 |
| Output Phases | 1 |
| Voltage - Supply (Vcc/Vdd) | 7V ~ 40V |
| Frequency - Switching | 1kHz ~ 200kHz |
| Duty Cycle (Max) | 45% (Typ) |
| Synchronous Rectifier | No |
| Clock Sync | No |
| Serial Interfaces | - |
| Control Features | Dead Time Control, Frequency Control |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 16-SOIC (0.154", 3.90mm Width) |
| Supplier Device Package | 16-SOP |
| Base Product Number | - |
| Grade | - |
| Qualification | - |
Parts with Similar Specifications
| Product Attribute |  |
 |
 |
 |
| Part Number | TL494BD | TL494BDG | TL494BDR2 | TL494BDR2G |
| Manufacturer | onsemi | onsemi | onsemi | onsemi |
| RoHS Status | RoHS non-compliant | RoHS non-compliant | ROHS3 Compliant | |
| Description | IC REG CTRLR BCK/PSH-PULL 16SOIC | IC REG CTRLR BCK/PSH-PULL 16SOIC | IC REG CTRLR BCK/PSH-PULL 16SOIC | IC REG CTRLR BCK/PSH-PULL 16SOIC |
| Series | SWITCHMODE™ | SWITCHMODE™ | SWITCHMODE™ | SWITCHMODE™ |
| Packaging | Tube | Tube | Tape & Reel (TR) | Tape & Reel (TR)-->Cut Tape (CT) |
