TLC072CDGNR
lmages are for reference only.TLC072CDGNR
IC OPAMP GP 2 CIRCUIT 8HVSSOP
Datasheet8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad
23,281 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
General Purpose Amplifier 2 Circuit 8-HVSSOP
TLC072CDGNR
| Category | Integrated Circuits (ICs) - Linear - Amplifiers |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Amplifier Type | General Purpose |
| Number of Circuits | 2 |
| Output Type | - |
| Slew Rate | 19V/µs |
| Gain Bandwidth Product | 10 MHz |
| Current - Input Bias | 1.5 pA |
| Voltage - Input Offset | 390 µV |
| Current - Supply | 2.1mA (x2 Channels) |
| Voltage - Supply Span (Min) | 4.5 V |
| Voltage - Supply Span (Max) | 16 V |
| Operating Temperature | 0°C ~ 70°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad |
| Supplier Device Package | 8-HVSSOP |
| Base Product Number | TLC072 |
| Current - Output / Channel | 57 mA |
| -3db Bandwidth | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
 |
 |
| Part Number | TLC072CDGN | TLC072CDGNRG4 | TLC072CD | TLC072CDG4 |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC OPAMP GP 2 CIRCUIT 8HVSSOP | IC OPAMP GP 2 CIRCUIT 8HVSSOP | IC OPAMP GP 2 CIRCUIT 8SOIC | IC OPAMP GP 2 CIRCUIT 8SOIC |
| Series | - | - | - | - |
| Packaging | Tube | Tape & Reel (TR) | Tube | Tube |
