TLE94110ELXUMA1
lmages are for reference only.TLE94110ELXUMA1
IC HALF BRIDGE DRVR 500MA 24SSOP
Datasheet24-LSSOP (0.154", 3.90mm Width) Exposed Pad
77,636 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Half Bridge (10) Driver AC Motors, DC Motors, General Purpose Power MOSFET PG-SSOP-24-4
TLE94110ELXUMA1
| Category | Integrated Circuits (ICs) - Power Management PMIC - Full Half-Bridge H Bridge Drivers |
| Manufacturer | Infineon Technologies |
| Series | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| Output Configuration | Half Bridge (10) |
| Applications | AC Motors, DC Motors, General Purpose |
| Interface | SPI |
| Load Type | Inductive |
| Technology | Power MOSFET |
| Rds On (Typ) | 850mOhm LS, 850mOhm HS |
| Current - Output / Channel | 500mA |
| Current - Peak Output | 2A |
| Voltage - Supply | 3V ~ 5.5V |
| Voltage - Load | 5.5V ~ 20V |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Features | - |
| Fault Protection | Over Temperature, Short Circuit, UVLO |
| Mounting Type | Surface Mount |
| Package / Case | 24-LSSOP (0.154", 3.90mm Width) Exposed Pad |
| Supplier Device Package | PG-SSOP-24-4 |
| Base Product Number | TLE94110 |
| Grade | - |
| Qualification | - |
