Product CatalogPart Number
TN2-5V-3
Manufacturer
Panasonic Electric WorksDescription
RELAY GENERAL PURPOSE DPDT 1A 5V
Datasheet
DatasheetPackage
-
In Stock
21,285 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
TN2-5V-3
TN2-5V-3
lmages are for reference only.Payment Methods
Delivery Services
General Purpose Relay DPDT (2 Form C) Through Hole
Quick Inquiry
TN2-5V-3
Specifications
| Category | Relays - Signal Relays-Up to 2 Amps - |
| Manufacturer | Panasonic Electric Works |
| Series | TN |
| Packaging | Tube |
| RoHS Status | |
| Mounting Type | Through Hole |
| Coil Voltage | 5VDC |
| Contact Form | DPDT (2 Form C) |
| Contact Rating (Current) | 1 A |
| Switching Voltage | 125VAC, 110VDC - Max |
| Load - Max Switching | 125VA, 110W |
| Coil Type | Non Latching |
| Features | - |
| Termination Style | PC Pin |
| Seal Rating | Sealed - Fully |
| Coil Insulation | - |
| Must Operate Voltage | 3.75 VDC |
| Must Release Voltage | 0.5 VDC |
| Operate Time | 3 ms |
| Release Time | 3 ms |
| Operating Temperature | -40°C ~ 70°C |
| Contact Material | Silver (Ag), Gold (Au) |
| Approval Agency | CSA, UR |
| Relay Type | General Purpose |
| Grade | - |
| Qualification | - |
| Base Product Number | TN2-5V |
| Coil Current | 28.1 mA |
| Coil Resistance | 178 Ohms |
