TNY289PG
lmages are for reference only.TNY289PG
IC OFFLINE SWITCH FLYBACK 8DIP
Datasheet8-DIP (0.300", 7.62mm), 7 Leads
76,445 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Converter Offline Flyback Topology 124kHz ~ 140kHz 8-PDIP-C
TNY289PG
| Category | Integrated Circuits (ICs) - Power Management PMIC - AC DC Converters-Offline Switches |
| Manufacturer | Power Integrations |
| Series | TinySwitch®-4 |
| Packaging | Tube |
| RoHS Status | RoHS Compliant |
| Output Isolation | Isolated |
| Internal Switch(s) | Yes |
| Voltage - Breakdown | 725V |
| Topology | Flyback |
| Voltage - Supply (Vcc/Vdd) | - |
| Duty Cycle | 67% |
| Frequency - Switching | 124kHz ~ 140kHz |
| Power (Watts) | 18 W |
| Fault Protection | Current Limiting, Open Loop, Over Temperature, Over Voltage, Short Circuit |
| Control Features | EN |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Package / Case | 8-DIP (0.300", 7.62mm), 7 Leads |
| Supplier Device Package | 8-PDIP-C |
| Mounting Type | Through Hole |
| Base Product Number | TNY289 |
| Voltage - Start Up | - |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | TNY280GN | TNY280GN-TL | TNY280PG | TNY280PN |
| Manufacturer | Power Integrations | Power Integrations | Power Integrations | Power Integrations |
| RoHS Status | RoHS Compliant | RoHS Compliant | RoHS Compliant | RoHS Compliant |
| Description | IC OFFLINE SWITCH FLYBACK 8SMD | IC OFFLINE SWITCH FLYBACK 8SMD | IC OFFLINE SWITCH FLYBACK 8DIP | IC OFFLINE SWITCH FLYBACK 8DIP |
| Series | TinySwitch®-III | TinySwitch®-III | TinySwitch®-III | TinySwitch®-III |
| Packaging | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tube | Tube |
