Product CatalogPart Number
TPD3215M
Manufacturer
TransphormDescription
MOSFET 2N-CH 600V 70A MODULE
Datasheet
DatasheetPackage
Module
In Stock
13,625 piece(s)
Unit Price
Please Contact Us
Lead Time
Can Ship Immediately
Request for Quotation
TPD3215M
TPD3215M
lmages are for reference only.Payment Methods
Delivery Services
Mosfet Array 600V 70A (Tc) 470W Through Hole Module
Quick Inquiry
TPD3215M
Specifications
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Transphorm |
| Series | - |
| Packaging | Bulk |
| RoHS Status | |
| Technology | GaNFET (Gallium Nitride) |
| Configuration | 2 N-Channel (Half Bridge) |
| FET Feature | - |
| Drain to Source Voltage (Vdss) | 600V |
| Current - Continuous Drain (Id) @ 25°C | 70A (Tc) |
| Rds On (Max) @ Id, Vgs | 34mOhm @ 30A, 8V |
| Vgs(th) (Max) @ Id | - |
| Gate Charge (Qg) (Max) @ Vgs | 28nC @ 8V |
| Input Capacitance (Ciss) (Max) @ Vds | 2260pF @ 100V |
| Power - Max | 470W |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Mounting Type | Through Hole |
| Package / Case | Module |
| Supplier Device Package | Module |
| Base Product Number | TPD3215 |
| Grade | - |
| Qualification | - |
