TPH3R704PC,LQ
lmages are for reference only.TPH3R704PC,LQ
MOSFET N-CH 40V 82A 8SOP
Datasheet8-PowerVDFN
60,569 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 40 V 82A (Tc) 830mW (Ta), 90W (Tc) Surface Mount 8-SOP Advance (5x5)
TPH3R704PC,LQ
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Toshiba Semiconductor and Storage |
| Series | U-MOSIX-H |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 40 V |
| Current - Continuous Drain (Id) @ 25°C | 82A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Rds On (Max) @ Id, Vgs | 3.7mOhm @ 41A, 10V |
| Vgs(th) (Max) @ Id | 2.4V @ 300µA |
| Vgs (Max) | ±20V |
| Input Capacitance (Ciss) (Max) @ Vds | 3615 pF @ 20 V |
| FET Feature | - |
| Power Dissipation (Max) | 830mW (Ta), 90W (Tc) |
| Operating Temperature | 175°C |
| Mounting Type | Surface Mount |
| Supplier Device Package | 8-SOP Advance (5x5) |
| Package / Case | 8-PowerVDFN |
| Base Product Number | TPH3R704 |
| Gate Charge (Qg) (Max) @ Vgs | 47 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
|
 |
 |
| Part Number | TPH3R704PL,L1Q | TPH3R70APL,L1Q | TPH3R70APL1,LQ | TPH11003NL,LQ |
| Manufacturer | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage | Toshiba Semiconductor and Storage |
| RoHS Status | ROHS3 Compliant | RoHS Compliant | ||
| Description | MOSFET N-CH 40V 92A 8SOP | MOSFET N-CH 100V 90A 8SOP | 150V U-MOS IX-H SOP-ADVANCE(N) 3 | MOSFET N CH 30V 32A 8SOP |
| Series | U-MOSIX-H | U-MOSIX-H | - | U-MOSVIII-H |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
