TPH4R008NH1,LQ

Specifications

Category	Discrete Semiconductor Products - Transistors - FETs-MOSFETs
Manufacturer	Toshiba Semiconductor and Storage
Series	-
Packaging	Tape & Reel (TR)
RoHS Status	ROHS3 Compliant
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	80 V
Current - Continuous Drain (Id) @ 25°C	146A (Ta), 116A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	10V
Rds On (Max) @ Id, Vgs	4mOhm @ 50A, 10V
Vgs(th) (Max) @ Id	4V @ 1mA
Vgs (Max)	±20V
Input Capacitance (Ciss) (Max) @ Vds	5300 pF @ 40 V
FET Feature	-
Power Dissipation (Max)	2.5W (Ta), 170W (Tc)
Operating Temperature	150°C
Mounting Type	Surface Mount
Supplier Device Package	8-SOP Advance (5x5.75)
Package / Case	8-PowerTDFN
Base Product Number	-
Gate Charge (Qg) (Max) @ Vgs	59 nC @ 10 V
Grade	-
Qualification	-

Product Attribute
Part Number	TPH4R008NH,L1Q	TPH4R008QM,LQ	TPH4R003NL,L1Q	TPH4R10ANL,L1Q
Manufacturer	Toshiba Semiconductor and Storage	Toshiba Semiconductor and Storage	Toshiba Semiconductor and Storage	Toshiba Semiconductor and Storage
RoHS Status	RoHS Compliant		RoHS Compliant	RoHS Compliant
Description	MOSFET N-CH 80V 60A 8SOP	POWER MOSFET TRANSISTOR SOP8-ADV	MOSFET N-CH 30V 40A 8SOP	MOSFET N-CH 100V 92A/70A 8SOP
Series	U-MOSVIII-H	U-MOSIX-H	U-MOSVIII-H	U-MOSVIII-H
Packaging	Tape & Reel (TR)-->Cut Tape (CT)	Tape & Reel (TR)-->Cut Tape (CT)	Tape & Reel (TR)-->Cut Tape (CT)	Tape & Reel (TR)-->Cut Tape (CT)
