TPS23753APW
lmages are for reference only.TPS23753APW
IC POE CNTRL 1 CHANNEL 14TSSOP
Datasheet14-TSSOP (0.173", 4.40mm Width)
59,496 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
Power Over Ethernet Controller 1 Channel 802.3at (PoE+), 802.3af (PoE) 14-TSSOP
TPS23753APW
| Category | Integrated Circuits (ICs) - Power Management PMIC - Power Over Ethernet PoE Controllers |
| Manufacturer | Texas Instruments |
| Series | - |
| Packaging | Tube |
| RoHS Status | ROHS3 Compliant |
| Type | Controller (PD), DC/DC |
| Number of Channels | 1 |
| Power - Max | 13 W |
| Internal Switch(s) | Both |
| Auxiliary Sense | No |
| Standards | 802.3at (PoE+), 802.3af (PoE) |
| Voltage - Supply | 0V ~ 57V |
| Current - Supply | 580µA |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | 14-TSSOP (0.173", 4.40mm Width) |
| Supplier Device Package | 14-TSSOP |
| Base Product Number | TPS23753 |
| Product Attribute | |
 |
|
 |
| Part Number | TPS23753APW | TPS23753APWR | TPS23753APWR | TPS23753PW |
| Manufacturer | Texas Instruments | Texas Instruments | Texas Instruments | Texas Instruments |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | IC POE CNTRL 1 CHANNEL 14TSSOP | IC POE CNTRL 1 CHANNEL 14TSSOP | IC POE CNTRL 1 CHANNEL 14TSSOP | IC POE CNTRL 1 CHANNEL 14TSSOP |
| Series | - | - | - | - |
| Packaging | Tube | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tube |
