TRS200RID
lmages are for reference only.TRS200RID
600V 200A TD RK5 FUSE SMARTSPO
DatasheetCylindrical, Blade Terminals
83,099 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
200A 600 VAC 600 VDC Fuse Cartridge Requires Holder
TRS200RID
| Category | Circuit Protection - Electrical-Specialty Fuses - |
| Manufacturer | Mersen USA Newburyport-MA L.L.C. |
| Series | TRS-R |
| Packaging | Box |
| RoHS Status | ROHS3 Compliant |
| Mounting Type | Requires Holder |
| Fuse Type | Cartridge |
| Current Rating (Amps) | 200A |
| Voltage Rating - AC | 600 VAC |
| Response Time | Slow Blow |
| Applications | Electrical, Industrial |
| Features | Indicating |
| Class | RK5 |
| Approval Agency | CSA, UL |
| Operating Temperature | - |
| Breaking Capacity @ Rated Voltage | 200kA AC, 100kA DC |
| Package / Case | Cylindrical, Blade Terminals |
| Size / Dimension | 1.811" Dia x 9.606" L (46.00mm x 244.00mm) |
| Base Product Number | - |
| Voltage Rating - DC | 600 VDC |
| Grade | - |
| Qualification | - |
| Melting I²t | - |
| DC Cold Resistance | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | TRS200R | TRS1-1/4R | TRS1-6/10R | TRS100R |
| Manufacturer | Mersen USA Newburyport-MA L.L.C. | Mersen USA Newburyport-MA L.L.C. | Mersen USA Newburyport-MA L.L.C. | Mersen USA Newburyport-MA L.L.C. |
| RoHS Status | ROHS3 Compliant | RoHS non-compliant | RoHS non-compliant | RoHS non-compliant |
| Description | 600V 200A 9 5/8X1 13/16 T | 600V 1 1/4A 5X13/16 TD FUSE | 600V 1 6/10A 5X13/16 TD FUSE | 600V 100A 7 7/8X1 5/16 TD |
| Series | TRS-R | TRS-R | TRS-R | TRS-R |
| Packaging | Bulk | Box | Box | Box |
