TSM056NH04LCR RLG
lmages are for reference only.TSM056NH04LCR RLG
40V, 54A, SINGLE N-CHANNEL POWER
Datasheet8-PowerTDFN
64,254 piece(s)
Please Contact Us
Can Ship Immediately
Request for Quotation
Payment Methods
Delivery Services
N-Channel 40 V 18A (Ta), 54A (Tc) 78.9W (Tc) Surface Mount 8-PDFNU (5x6)
TSM056NH04LCR RLG
| Category | Discrete Semiconductor Products - Transistors - FETs-MOSFETs |
| Manufacturer | Taiwan Semiconductor Corporation |
| Series | PerFET™ |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) |
| RoHS Status | ROHS3 Compliant |
| FET Type | N-Channel |
| Technology | MOSFET (Metal Oxide) |
| Drain to Source Voltage (Vdss) | 40 V |
| Current - Continuous Drain (Id) @ 25°C | 18A (Ta), 54A (Tc) |
| Drive Voltage (Max Rds On, Min Rds On) | 4.5V, 10V |
| Rds On (Max) @ Id, Vgs | 5.6mOhm @ 27A, 10V |
| Vgs(th) (Max) @ Id | 2.2V @ 250µA |
| Vgs (Max) | ±16V |
| Input Capacitance (Ciss) (Max) @ Vds | 1940 pF @ 25 V |
| FET Feature | - |
| Power Dissipation (Max) | 78.9W (Tc) |
| Operating Temperature | -55°C ~ 175°C (TJ) |
| Mounting Type | Surface Mount |
| Supplier Device Package | 8-PDFNU (5x6) |
| Package / Case | 8-PowerTDFN |
| Base Product Number | - |
| Gate Charge (Qg) (Max) @ Vgs | 30.4 nC @ 10 V |
| Grade | - |
| Qualification | - |
| Product Attribute |  |
 |
 |
 |
| Part Number | TSM056NH04CR RLG | TSM056NH04CV RGG | TSM056NH04LCV RGG | TSM250NB06LCV RGG |
| Manufacturer | Taiwan Semiconductor Corporation | Taiwan Semiconductor Corporation | Taiwan Semiconductor Corporation | Taiwan Semiconductor Corporation |
| RoHS Status | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant | ROHS3 Compliant |
| Description | 40V, 54A, SINGLE N-CHANNEL POWER | 40V, 54A, SINGLE N-CHANNEL POWER | 40V, 54A, SINGLE N-CHANNEL POWER | 60V, 27A, SINGLE N-CHANNEL POWER |
| Series | PerFET™ | PerFET™ | PerFET™ | - |
| Packaging | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) | Tape & Reel (TR)-->Cut Tape (CT) |
